Mechanical Vacuum Booster System in Andhra Pradesh

Mechanical Vacuum Booster System in Andhra Pradesh

Mechanical Vacuum Booster System in Andhra Pradesh

Request For Quotation

working principle

Manufacturing mechanical vacuum booster systems involves meticulous steps to ensure quality and efficiency. The process commences with design and engineering, crafting detailed blueprints based on performance requirements and standards. Materials are then procured, encompassing metal parts, seals, valves, motors, and electronics. Next, components are fabricated through machining, casting, or forging. Skilled technicians meticulously assemble these parts, adhering to precise procedures and rigorous quality control measures. Testing follows suit, scrutinizing functionality, safety, and performance under diverse conditions. Quality control remains paramount throughout, with inspections conducted at each stage. Post-testing, systems are securely packaged for shipping, often accompanied by installation support and ongoing customer service. Continuous improvement is pursued through feedback analysis, fostering innovation and product enhancement.

Technical Specifications

AIR COOLED SERIES MODEL && ITS DETAIL TECHNICAL SPECIFICATION

PARTICULARSIVMA-9IVMA-11IVMA-13IVMA-15IVMA-17IVMA-19IVMA-21IVMA-23IVMA-25IVMA-27IVMA-29IVMA-31
DISPLACEMENT LPM @1450 RPM22503650500075001650019500310005000087500137500232000321500
DISPLACEMENT LPM @2850 RPM450073001000015000233003900062000***************
Recommended Motor KW @1450 RPM1.11.12.22.23.75.55.512.518.5304590
Recommended Motor KW @1450 RPM2.22.23.73.75.57.511***************
Max P(m bar)1001001001009085656060555050

WATER COOLED SERIES MODEL & ITS DETAIL TECHNICAL SPECIFICATION

PARTICULARSIVMW-10IVMW-12IVMW-16IVMW-22
DISPLACEMENT LPM @1450 RPM4500140003600057000
DISPLACEMENT LPM @1450 RPM9100280007200011400
Recommended Motor KW @1450 RPM2.23.75.57.5
Recommended Motor KW @1450 RPM3.75.51115
Max P(m bar)75655050

material of construction

  • Construction of Vacuum Booster Compressor involves Two Counter Rotating Rotor ( Lobe )  with a Special Contour. These Rotate with a Very Finite and Sharp Clearance and without any Physical Contact. Variance in design offers Twin Lobe Booster in air cooled or water-cooled execution.
  • The Booster are Relatively Consume Less Power and Deliver High Performance. They provide and Improvement in Vacuum of the Order of 0.001 Torr. They Generate Higher Pumping Speeds and That too at Low Pressure.
  • The Boosters are used in series with any Vacuum Pumps Like Watering, Oil Seal and Dry Type Or Ejector.
  • The Booster are help to achieve a reduce Downtime for Vacuum Machine.
  • They are Properly installed and Maintain Well, they provide years of Uninterrupted Service.
  • features

  • Vacuum Boosters are Power Efficient. Very often a Combination of Vacuum Booster and Suitable Back up Pump Result in Reduced a Power Consumption Per Unit of Pumping Speed. They Provide High Pumping Speed Even at Low Pressure.
  • Mechanical Vacuum Booster is Dry Pump, as it Does Not Use any Pumping Fluid.
  • Low Power Consumption Compare to any Type of High Vacuum Pump.
  • High Volumetric Efficiency.
  • Enables Operations in High Vacuum and Large Pumping Speed at Very Low Power Consumption and Hence Very Short Payback Period.
  • Low Maintanance.
  • Application

    IVC Pumps Pvt. Ltd. is a leading Manufacturer, Supplier and Exporter of Mechanical Vacuum Booster System in Andhra Pradesh, India.

    Modern industries require vacuum systems that deliver consistent performance, higher efficiency, lower energy consumption, and dependable operation.

    A Mechanical Vacuum Booster System is designed to improve vacuum performance by increasing pumping capacity and helping processes reach the required vacuum level more efficiently.

    We offer robust Mechanical Vacuum Booster Systems engineered for demanding industrial processes where reliability, productivity, and efficient vacuum generation are essential.

    From chemical and pharmaceutical manufacturing to food processing, vacuum packaging, and process industries, these systems provide an effective solution for businesses looking to improve their vacuum operations.

    Benefits of Using a Mechanical Vacuum Booster:

    Installing a mechanical vacuum booster can significantly improve the performance of an existing vacuum system.

    Major benefits include:

    • Higher pumping speed: Removes gases and vapours more quickly.
    • Better vacuum level: Helps processes reach the required vacuum efficiently.
    • Shorter processing time: Faster evacuation can reduce production cycle duration.
    • Improved productivity: Higher vacuum capacity supports greater process output.
    • Energy optimization: Boosters improve efficiency without enlarging primary pumps.
    • Stable performance: Maintains consistent vacuum conditions during continuous operation.
    • Long-term reliability: Industrial-grade design supports demanding production environments.

    Why Choose an Industrial Vacuum Booster System?

    Businesses looking to improve their vacuum processes should consider more than just maximum vacuum level. The complete system should provide the correct balance of pumping speed, efficiency, reliability, operating cost, and maintainability.

    A properly selected Mechanical Vacuum Booster System can help businesses achieve:

    • Faster production cycles
    • Improved vacuum stability
    • Lower process downtime
    • Better energy utilization
    • Increased production capacity
    • Reliable long-term operation
    • Reduced total operating cost

    Why Choose IVC Pumps Pvt. Ltd.?

    We provide industrial vacuum solutions designed for performance-oriented applications. According to the product information shown, the Mechanical Vacuum Booster System focuses on four major priorities:

    • High Vacuum Level
    • Robust & Durable Construction
    • Energy-Efficient Operation
    • Easy Maintenance

    These characteristics make the system suitable for industries seeking better vacuum performance, higher efficiency, and maximum productivity.

    Frequently Asked Questions:

    Q1. What is a mechanical vacuum booster?
    A mechanical vacuum booster is a vacuum pumping device used with a backing pump to increase pumping speed and improve vacuum system performance.

    Q2. Why is a vacuum booster used?
    It is used to achieve faster evacuation, higher pumping capacity, improved productivity, and better vacuum efficiency.

    Q3. Which industries use mechanical vacuum boosters?
    They are commonly used in chemical, pharmaceutical, food and beverage, vacuum packaging, and other process industries.

    Q4. Can a mechanical vacuum booster reduce energy consumption?
    A properly designed booster system can improve overall vacuum efficiency and may reduce the energy required to achieve the desired process performance.

    Q5. How do I select the correct vacuum booster?
    Selection depends on required vacuum level, pumping speed, gas load, process conditions, backing pump capacity, and application requirements.

    IVC Pumps Pvt. Ltd. is a leading Manufacturer, Supplier and Exporter of Mechanical Vacuum Booster System in Andhra Pradesh, India Including other locations like Anantapur, Chittoor, East Godavari, Guntur, Krishna, Kurnool, Prakasam, Srikakulam, Sri Potti Sriramulu Nellore, Visakhapatnam, Vizianagaram, West Godavari, Kadapa, Visakhapatnam, Vijayawada, Nellore, Kurnool, Rajamahendravaram, Tirupati, Kakinada, Srikakulam, Yemmiganur, Nagarjunakoṇḍa, Rajahmundry, Adoni, Amaravati, Chandragiri, Dowlaiswaram, Eluru, Guntur, Kadapa, Kakinada.
