Mechanical Vacuum Booster System in Egypt

Request For Quotation

working principle

Manufacturing mechanical vacuum booster systems involves meticulous steps to ensure quality and efficiency. The process commences with design and engineering, crafting detailed blueprints based on performance requirements and standards. Materials are then procured, encompassing metal parts, seals, valves, motors, and electronics. Next, components are fabricated through machining, casting, or forging. Skilled technicians meticulously assemble these parts, adhering to precise procedures and rigorous quality control measures. Testing follows suit, scrutinizing functionality, safety, and performance under diverse conditions. Quality control remains paramount throughout, with inspections conducted at each stage. Post-testing, systems are securely packaged for shipping, often accompanied by installation support and ongoing customer service. Continuous improvement is pursued through feedback analysis, fostering innovation and product enhancement.

Technical Specifications

AIR COOLED SERIES MODEL && ITS DETAIL TECHNICAL SPECIFICATION

PARTICULARS	IVMA-9	IVMA-11	IVMA-13	IVMA-15	IVMA-17	IVMA-19	IVMA-21	IVMA-23	IVMA-25	IVMA-27	IVMA-29	IVMA-31
DISPLACEMENT LPM @1450 RPM	2250	3650	5000	7500	16500	19500	31000	50000	87500	137500	232000	321500
DISPLACEMENT LPM @2850 RPM	4500	7300	10000	15000	23300	39000	62000	***	***	***	***	***
Recommended Motor KW @1450 RPM	1.1	1.1	2.2	2.2	3.7	5.5	5.5	12.5	18.5	30	45	90
Recommended Motor KW @1450 RPM	2.2	2.2	3.7	3.7	5.5	7.5	11	***	***	***	***	***
Max P(m bar)	100	100	100	100	90	85	65	60	60	55	50	50

WATER COOLED SERIES MODEL & ITS DETAIL TECHNICAL SPECIFICATION

PARTICULARS	IVMW-10	IVMW-12	IVMW-16	IVMW-22
DISPLACEMENT LPM @1450 RPM	4500	14000	36000	57000
DISPLACEMENT LPM @1450 RPM	9100	28000	72000	11400
Recommended Motor KW @1450 RPM	2.2	3.7	5.5	7.5
Recommended Motor KW @1450 RPM	3.7	5.5	11	15
Max P(m bar)	75	65	50	50

material of construction

Construction of Vacuum Booster Compressor involves Two Counter Rotating Rotor ( Lobe ) with a Special Contour. These Rotate with a Very Finite and Sharp Clearance and without any Physical Contact. Variance in design offers Twin Lobe Booster in air cooled or water-cooled execution.

The Booster are Relatively Consume Less Power and Deliver High Performance. They provide and Improvement in Vacuum of the Order of 0.001 Torr. They Generate Higher Pumping Speeds and That too at Low Pressure.

The Boosters are used in series with any Vacuum Pumps Like Watering, Oil Seal and Dry Type Or Ejector.

The Booster are help to achieve a reduce Downtime for Vacuum Machine.

They are Properly installed and Maintain Well, they provide years of Uninterrupted Service.

features

Vacuum Boosters are Power Efficient. Very often a Combination of Vacuum Booster and Suitable Back up Pump Result in Reduced a Power Consumption Per Unit of Pumping Speed. They Provide High Pumping Speed Even at Low Pressure.

Mechanical Vacuum Booster is Dry Pump, as it Does Not Use any Pumping Fluid.

Low Power Consumption Compare to any Type of High Vacuum Pump.

High Volumetric Efficiency.

Enables Operations in High Vacuum and Large Pumping Speed at Very Low Power Consumption and Hence Very Short Payback Period.

Low Maintanance.

Application

IVC Pumps Pvt. Ltd. is a prominent Manufacturer and Supplier of Mechanical Vacuum Booster System in Egypt.

A Mechanical Vacuum Booster System is a high-performance auxiliary device designed to significantly improve the capacity and efficiency of existing vacuum pump systems.

It works by mechanically accelerating the evacuation process, allowing the primary vacuum pump to achieve deeper vacuum levels with reduced load.

This system is widely used in industrial processes where high vacuum performance, faster evacuation, and stable pressure control are critical.

IVC Pumps Pvt. Ltd. designs advanced Mechanical Vacuum Booster Systems that ensure reliable, continuous, and energy-efficient vacuum operation for demanding industrial applications.

We also deal in Vacuum Pumps, including Liquid Ring Vacuum Pumps, Water Ring Vacuum Pumps, Single Stage and Two Stage Liquid Ring Vacuum Pumps, Mono Block Water Ring Vacuum Pumps, Twin Lobe Roots Blowers, Mechanical Vacuum Booster Systems, Oil Seal Rotary Vacuum Pumps and Pneumatic Conveying System.

Key Features of Mechanical Vacuum Booster System:

• High-speed mechanical rotor design
• Compatible with multiple vacuum pump types
• Compact and modular construction
• Low vibration and low noise operation
• Heavy-duty industrial-grade build
• Corrosion-resistant materials available
• Easy installation and integration
• Optional automation and control systems

Why Choose Mechanical Vacuum Booster System?

Mechanical vacuum boosters are preferred for industries requiring high productivity and efficient vacuum handling.

• Enhances overall vacuum pump performance
• Reduces evacuation time significantly
• Improves production efficiency in industrial processes
• Lowers energy consumption of primary vacuum pumps
• Ensures stable and consistent vacuum levels
• Suitable for continuous heavy-duty operations
• Increases system reliability and uptime

FAQs – Mechanical Vacuum Booster System:

Q1. What is the main function of a vacuum booster system?
It enhances the performance and pumping speed of an existing vacuum pump system.

Q2. Does it work independently?
No, it operates along with a primary vacuum pump to boost efficiency.

Q3. Is it suitable for continuous operation?
Yes, it is designed for continuous industrial-duty applications.

Q4. Can it handle corrosive gases?
Yes, with appropriate material selection, it can handle corrosive and vapor-laden gases.

IVC Pumps Pvt. Ltd. is a prominent Manufacturer and Supplier of Mechanical Vacuum Booster System in Egypt including other locations like Cairo, Giza, Alexandria, Shubrā al Khaymah, Al Mansurah, Tanta, Asyut, Luxor, Port Said, Suez, Ismailia, and other major industrial regions across Egypt.

Call Us:
+91 9904707781
+91 9904707785

Email Us:
ivc@ivcvacuumpumps.com

For more information or to request a quote, feel free to contact IVC Pumps Pvt. Ltd. today!

View Product: Click Here
