working principle

Twin Lobe Roots Blower available for flow rates from 60 M3 / Hr to 7,718 M3 / Hr to Working Pressure upto 1 Kg / Cm2. Roots Blower are Low Pressure High Volume Positive Displacement Machine. These Machine Operate on Differential Pressure and Constant Volume Characteristic.

Our Range Spans over 14 Air Cooled and 5 Water Cooled Models.

These Compressors are designed in such a way that the same can have vertical or horizontal air flow. Further, the Compressor with its standard accessories is being supplied as one compact unit which makes it very easy to install. It is also available as bare machine for replacement.

Blower are Suitable for Both Vacuum & Pressure Application. Pressures Note Developed inside the Blower by the demand of the System ( Application ). Differential Pressure, therefore, varies to meet the Load Condition and System Resistance.

Technical Specifications

MODEL CAPACITY ( M3 / HR )
SPEED RPM
MAX. POWER ( HP )
IVBA - 1060 - 2331610 - 285015
IVBA - 1281 - 3891368 - 285020
IVBA - 14142 - 5421450 - 285030
IVBA - 16177 - 8001196 - 273240
IVBA - 19318 - 9871230 - 220350
IVBA - 22523 - 1,5271095 - 203575
IVBA - 26782 - 2,1821030 - 1825120
IVBA - 30879 - 2,478716 - 1287120
IVBA - 361,259 - 3,658606 - 1088180
IVBA - 422,197 - 5,822606 - 1088300
IVBA - 503,157 - 7,718512 - 856370

material of construction

  • Lobes or Rotors: The lobes are meticulously engineered to precise tolerances to ensure optimal performance and minimal wear over time. Their interlocking design ensures efficient gas transfer while minimizing internal leakage.
  • Casing: The casing or housing encloses the rotors and provides structural support. It is typically crafted from cast iron or other robust materials to withstand the forces generated during operation.
  • Bearings and Shaft: High-quality bearings support the rotor shafts, ensuring smooth rotation and minimizing frictional losses. These components are crucial for maintaining the blower’s efficiency and longevity.
  • Inlet and Outlet Ports: The blower features inlet and outlet ports for the entry and exit of gas. These ports are strategically located to optimize gas flow and minimize pressure losses.
  • features

  • Suitable for Vacuum & Pressure Application
  • Positive displacement machines with constant volume characteristics.
  • Oil Free Delivery
  • Easy Maintenance.
  • Rugged Construction For Heavy Duty Application.
  • High precision helical timing gears for reliability & long life
  • Split casing design facilitates easy maintenance and repair.
  • Low Specific Power Consumption
  • Heat resistant
  • Adjustable machine feet permit both horizontal & vertical flow of medium
  • Application

    IVC Pumps Pvt. Ltd. is a trusted manufacturer, supplier, and exporter of advanced Twin Lobe Roots Blowers in Yemen, engineered to deliver exceptional performance, energy efficiency, and long-term reliability.

    Modern industries rely on efficient air movement systems to maintain productivity, optimize processes, and reduce operational costs. A Twin Lobe Roots Blower plays a vital role in delivering a continuous flow of air or gas across multiple industrial applications. Its robust design and dependable performance make it an essential piece of equipment for industries that demand uninterrupted operations.

    Our blowers support various industries by providing stable airflow, low maintenance requirements, and superior durability. With precision engineering and modern manufacturing technology, we offer solutions that help businesses improve productivity while reducing downtime.

    The lobes do not come into contact with each other, which minimizes wear and ensures smooth operation. The blower creates a continuous, pulsation-free airflow suitable for numerous industrial processes. Industries prefer Twin Lobe Roots Blowers because they provide consistent pressure and high operational efficiency.

    Why Industries Choose IVC Pumps Pvt. Ltd.?

    IVC Pumps Pvt. Ltd. has built a strong reputation by delivering dependable industrial air handling solutions.

    We stand out because we offer:

    • Advanced engineering technology
    • High-quality manufacturing standards
    • Energy-efficient designs
    • Customized blower solutions
    • Durable construction
    • Strict quality control procedures
    • Timely product delivery
    • Technical support services
    • Global supply capabilities

    Our team focuses on delivering products that maximize operational efficiency and business performance.

    Understanding the Working Principle:

    1: Air Intake
    Atmospheric air enters the blower through the inlet port.

    2: Lobe Rotation
    Two synchronized lobes rotate without touching each other.

    3: Air Transfer
    The rotating lobes trap air and move it toward the discharge port.

    4: Pressure Generation
    The blower compresses and transfers air at a constant pressure.

    5: Air Discharge
    The processed air exits smoothly into the application system.

    Industries That Use Twin Lobe Roots Blowers:

    Twin Lobe Roots Blowers support numerous industries, including:

    1. Wastewater treatment plants
    2. Cement industries
    3. Chemical processing plants
    4. Food processing industries
    5. Pharmaceutical industries
    6. Aquaculture systems
    7. Pneumatic conveying systems
    8. Power generation plants
    9. Paper manufacturing industries
    10. Textile industries

    Their versatility makes them suitable for multiple industrial environments.

    Frequently Asked Questions (FAQs):

    Q1. What is a Twin Lobe Roots Blower?
    A Twin Lobe Roots Blower is a positive displacement blower that transfers air or gas continuously using two rotating lobes.

    Q2. Does the blower provide oil-free air?
    Yes. It delivers clean and contamination-free air.

    Q3. Is the blower energy efficient?
    Yes. Its optimized design reduces energy consumption.

    Q4. Does IVC Pumps Pvt. Ltd. provide customized solutions?
    Yes. We offer customized blower configurations based on industrial requirements.

    Q5. Is regular maintenance required?
    Yes. Routine maintenance improves performance and extends equipment lifespan.

    IVC Pumps Pvt. Ltd. is a trusted manufacturer, supplier, and exporter of advanced Twin Lobe Roots Blowers in Yemen, including other locations like ‘Abs, ‘Adan [Aden], Aḍ-Ḍaḥi, Aḍ-Ḍāli’ [Dhale], Ad-Dīs, Al-Bayḍā’, Al-Ghayḍah, Al-Ḥabīlayn, Al-Ḥazm, Al-Ḥudaydah, Al-Jarrāḥī, Al-Khawkhah, Al-Maḥābishah, Al-Maḥwīt, Al-Manṣūrīyah, Al-Marāwi’ah, Al-Marhinah, Al-Milāḥah, Al-Misrākh, Al-Mukallā, Al-Qā’idah, Al-Qaṭn, Al-Quţay’, ‘Amrān, Ar-Rāhidah, Ash-Shihr, ‘Atāq, At-Tuḥaytā, At-Turbah, Az-Zaydīyah, Bājil, Bayḥān (al-Qiṣāb) [Beihan], Bayt al-Faqīh, Ḍaiḥān, Damt, Dhamār, Ghayl Bā Wazīr, Ḥajjah, Ḥaraḍ, Ḥays, Ibb, Ja’ār, Jiblah, Khamr, Laḥij (Al-Hawtah), Lawdar, Ma’bar, Maqbanah, Qa’ṭabah, Radā’, Rayḍah, Ṣa’dah, Saḥḥār, Ṣan’ā’ (incl. ar-Rawḍah) [Sana’a], Say’ūn, Shafar, Shibām, Ta’izz [Taiz], Tarīm, Yarīm, Zabīd, Zinjibār, Abyān, Al-Jawf, Al-Mahrah, Al-Maḥwīt [Mahweet], Amānah al-‘Āṣmah [Sana’a City], Ḥaḍramaūt [Hadhramaut], Laḥij [Laheg], Ma’rib [Mareb], Raymah, Ṣan’ā’, Shabwah, Sanaa, Ta‘izz, Al Ḩudaydah, Al Manşūrah, Ash Shaykh ‘Uthmān, Şa‘dah, At Tawāhī, Al Ma‘allā’, Al Bayḑā’, Laḩij, Al Masālīyah, Crater, Aş Şalw.
