Twin Lobe Roots Blower in Malaysia

Twin Lobe Roots Blower in Malaysia

Twin Lobe Roots Blower in Malaysia

Request For Quotation

working principle

Twin Lobe Roots Blower available for flow rates from 60 M3 / Hr to 7,718 M3 / Hr to Working Pressure upto 1 Kg / Cm2. Roots Blower are Low Pressure High Volume Positive Displacement Machine. These Machine Operate on Differential Pressure and Constant Volume Characteristic.

Our Range Spans over 14 Air Cooled and 5 Water Cooled Models.

These Compressors are designed in such a way that the same can have vertical or horizontal air flow. Further, the Compressor with its standard accessories is being supplied as one compact unit which makes it very easy to install. It is also available as bare machine for replacement.

Blower are Suitable for Both Vacuum & Pressure Application. Pressures Note Developed inside the Blower by the demand of the System ( Application ). Differential Pressure, therefore, varies to meet the Load Condition and System Resistance.

Technical Specifications

MODEL CAPACITY ( M3 / HR )
SPEED RPM
MAX. POWER ( HP )
IVBA - 1060 - 2331610 - 285015
IVBA - 1281 - 3891368 - 285020
IVBA - 14142 - 5421450 - 285030
IVBA - 16177 - 8001196 - 273240
IVBA - 19318 - 9871230 - 220350
IVBA - 22523 - 1,5271095 - 203575
IVBA - 26782 - 2,1821030 - 1825120
IVBA - 30879 - 2,478716 - 1287120
IVBA - 361,259 - 3,658606 - 1088180
IVBA - 422,197 - 5,822606 - 1088300
IVBA - 503,157 - 7,718512 - 856370

material of construction

  • Lobes or Rotors: The lobes are meticulously engineered to precise tolerances to ensure optimal performance and minimal wear over time. Their interlocking design ensures efficient gas transfer while minimizing internal leakage.
  • Casing: The casing or housing encloses the rotors and provides structural support. It is typically crafted from cast iron or other robust materials to withstand the forces generated during operation.
  • Bearings and Shaft: High-quality bearings support the rotor shafts, ensuring smooth rotation and minimizing frictional losses. These components are crucial for maintaining the blower’s efficiency and longevity.
  • Inlet and Outlet Ports: The blower features inlet and outlet ports for the entry and exit of gas. These ports are strategically located to optimize gas flow and minimize pressure losses.
  • features

  • Suitable for Vacuum & Pressure Application
  • Positive displacement machines with constant volume characteristics.
  • Oil Free Delivery
  • Easy Maintenance.
  • Rugged Construction For Heavy Duty Application.
  • High precision helical timing gears for reliability & long life
  • Split casing design facilitates easy maintenance and repair.
  • Low Specific Power Consumption
  • Heat resistant
  • Adjustable machine feet permit both horizontal & vertical flow of medium
  • Application

    IVC Pumps Pvt. Ltd. is a prominent Twin Lobe Roots Blower Manufacturer and Supplier in Malaysia.

    A twin lobe roots blower is a positive displacement rotary machine designed to deliver a constant, reliable volume of air or gas continuously.

    Their non-contact rotating parts ensure minimal wear, longer operational life, reduced maintenance needs, and consistent performance across demanding environments.

    We engineer our twin lobe roots blowers using advanced manufacturing techniques and high-quality materials.

    IVC Pumps Pvt. Ltd. supplies twin lobe roots blowers that deliver durability, energy efficiency, and dependable performance across industries.

    Benefits of Twin Lobe Roots Blowers:

    • Continuous & Uniform Airflow – Ideal for process stability
    • Low Operating Costs – Energy-efficient design
    • Minimal Downtime – Reliable and robust construction
    • Easy Maintenance – Simple internal mechanism
    • High Pressure Capability – Performs well under demanding conditions
    • Oil-Free Air Delivery – Suitable for sensitive applications
    • Long Service Life – Built for continuous industrial use
    • Stable Performance – Consistent output at variable loads
    • Low Vibration Levels – Enhances operational safety
    • Compact Design – Saves installation space
    • Quick Installation – Easy integration into existing systems

    Applications of Twin Lobe Roots Blower:

    Twin Lobe Roots Blowers are widely used in:

    • Wastewater treatment and aeration systems
    • Pneumatic conveying of powders, grains, and chemicals
    • Industrial vacuum systems
    • Chemical, pharmaceutical, and food processing plants
    • Aquaculture and fish farming aeration
    • Cement and mineral industries
    • Power plants and industrial combustion air systems

    FAQs – Twin Lobe Roots Blower:

    Q: Is the airflow oil-free?
    A: Yes, twin lobe roots blowers deliver completely oil-free air.

    Q: Can these blowers be used for continuous operation?
    A: Yes, designers build them for continuous-duty industrial applications.

    Q: Can these blowers operate continuously?
    A: Yes, they are designed for continuous and heavy-duty industrial operation.

    IVC Pumps Pvt. Ltd. is a prominent Twin Lobe Roots Blower Manufacturer and Supplier in Malaysia Including Location Like Kuala Lumpur, Seberang Jaya, Klang, Ipoh, George Town, Petaling Jaya, Kuantan, Shah Alam, Sungai Petani, Johor Bahru, Kota Bharu, Melaka, Kota Kinabalu, Seremban, Sandakan, Kuching, Kluang, Muar, Pasir Gudang, Kuala Terengganu, Sibu, Taiping, Kajang, Miri, Teluk Intan, Kulai, Alor Setar, Bukit Mertajam, Lahad Datu, Segamat, Tumpat, Keningau, Batu Pahat, Batu Gajah, Tuaran, Bayan Lepas, Port Dickson, Bintulu, Tawau, Simanggang, Labuan, Cukai, Butterworth, Putrajaya, Taman Johor Jaya, Kangar.

    Contact Details:
    Call Us: +91 9904707781, +91 9904707785
    Email Us: ivc@ivcvacuumpumps.com

    For more information or to request a quote, feel free to contact IVC Pumps Pvt. Ltd. today!
