working principle

Twin Lobe Roots Blower available for flow rates from 60 M3 / Hr to 7,718 M3 / Hr to Working Pressure upto 1 Kg / Cm2. Roots Blower are Low Pressure High Volume Positive Displacement Machine. These Machine Operate on Differential Pressure and Constant Volume Characteristic.

Our Range Spans over 14 Air Cooled and 5 Water Cooled Models.

These Compressors are designed in such a way that the same can have vertical or horizontal air flow. Further, the Compressor with its standard accessories is being supplied as one compact unit which makes it very easy to install. It is also available as bare machine for replacement.

Blower are Suitable for Both Vacuum & Pressure Application. Pressures Note Developed inside the Blower by the demand of the System ( Application ). Differential Pressure, therefore, varies to meet the Load Condition and System Resistance.

Technical Specifications

MODEL CAPACITY ( M3 / HR )
SPEED RPM
MAX. POWER ( HP )
IVBA - 1060 - 2331610 - 285015
IVBA - 1281 - 3891368 - 285020
IVBA - 14142 - 5421450 - 285030
IVBA - 16177 - 8001196 - 273240
IVBA - 19318 - 9871230 - 220350
IVBA - 22523 - 1,5271095 - 203575
IVBA - 26782 - 2,1821030 - 1825120
IVBA - 30879 - 2,478716 - 1287120
IVBA - 361,259 - 3,658606 - 1088180
IVBA - 422,197 - 5,822606 - 1088300
IVBA - 503,157 - 7,718512 - 856370

material of construction

  • Lobes or Rotors: The lobes are meticulously engineered to precise tolerances to ensure optimal performance and minimal wear over time. Their interlocking design ensures efficient gas transfer while minimizing internal leakage.
  • Casing: The casing or housing encloses the rotors and provides structural support. It is typically crafted from cast iron or other robust materials to withstand the forces generated during operation.
  • Bearings and Shaft: High-quality bearings support the rotor shafts, ensuring smooth rotation and minimizing frictional losses. These components are crucial for maintaining the blower’s efficiency and longevity.
  • Inlet and Outlet Ports: The blower features inlet and outlet ports for the entry and exit of gas. These ports are strategically located to optimize gas flow and minimize pressure losses.
  • features

  • Suitable for Vacuum & Pressure Application
  • Positive displacement machines with constant volume characteristics.
  • Oil Free Delivery
  • Easy Maintenance.
  • Rugged Construction For Heavy Duty Application.
  • High precision helical timing gears for reliability & long life
  • Split casing design facilitates easy maintenance and repair.
  • Low Specific Power Consumption
  • Heat resistant
  • Adjustable machine feet permit both horizontal & vertical flow of medium
  • Application

    IVC Pumps Pvt. Ltd. is a leading Twin Lobe Roots Blower Manufacturer and Supplier in Kenya.

    Twin Lobe Roots Blower is essential industrial equipment for efficient air and gas movement in various operational processes.

    IVC Pumps Pvt. Ltd. provides premium Twin Lobe Roots Blowers, ensuring reliable, durable, and high-performance industrial solutions.

    Operating on positive displacement, two rotating lobes trap and transfer air or gas without internal compression during operation.

    These blowers are ideal for systems requiring steady airflow at consistent low to medium pressure across various applications.

    Twin Lobe Roots Blowers use synchronized intermeshing rotors to move air or gas with precision and mechanical efficiency.

    This makes them ideal for applications requiring consistent and reliable air delivery.

    Specifications:

    IVC Pumps Pvt. Ltd. offers a range of Twin Lobe Roots Blowers with the following specifications:

    Flow Rate: 60 m³/hr to 7,718 m³/hr.
    Maximum Pressure: Up to 1 kg/cm².
    Power Range: 15 HP to 425 HP (11 kW to 315 kW).
    Cooling Options: Air Cooled and Water Cooled.
    Configurations: Horizontal and Vertical airflow.
    Design: Compact units for easy installation.

    Features:

    Robust Construction: Built with durable materials for long service life.
    High Efficiency: Optimized rotor design reduces power consumption.
    Low Noise Operation: Advanced sound-dampening technology minimizes noise levels.
    Compact Design: Saves space and allows easy installation.
    Low Maintenance: Simplified design reduces downtime and servicing costs.
    Versatile Drive Options: Compatible with electric motors, diesel engines, and more.
    Precision Engineering: Ensures minimal vibration and smooth operation.
    Leak-proof Design: Prevents air/gas loss and improves operational efficiency.

    Applications:

    Distillation Coating
    Degassing
    Vacuum Impregnation
    Vacuum Freeze-Drying
    Crystallization
    Refining of Oil Industries
    Space Simulation
    Polymerization

    We also deal in Vacuum Pumps, including Liquid Ring Vacuum Pumps, Water Ring Vacuum Pumps, Single Stage and Two Stage Liquid Ring Vacuum Pumps, Mono Block Water Ring Vacuum Pumps, Twin Lobe Roots Blowers, Mechanical Vacuum Booster Systems, Oil Seal Rotary Vacuum Pumps and Pneumatic Conveying System.

    FAQs:

    Q1: What industries commonly use Twin Lobe Roots Blowers?
    A1: Industries like wastewater treatment, chemical processing, cement, food and beverage, pharmaceuticals, and power plants widely use Twin Lobe Roots Blowers.

    Q2: What is the difference between a Twin Lobe and a Tri-Lobe Roots Blower?
    A2: Twin Lobe blowers have two lobes and generally offer higher airflow with moderate pressure, while Tri-Lobe blowers have three lobes and provide smoother airflow with less pulsation, typically at lower pressure.

    IVC Pumps Pvt. Ltd. is Twin Lobe Roots Blower in Kenya Including Nairobi, Mombasa, Nakuru, Eldoret, Kisumu, Kikuyu, Lunga-Lunga, Habaswein, Ongata Rongai, Garissa, Molo, Kitenkela, Kiambu, Ramu, Kilifi, Malindi, Vihiga, Machakos, Kisii, Ngong, Mumias, Thika, Nyeri, Kakamega, Wajir, Ukunda, Nandi Hills, Narok, Embu, Kitale, Wundanyi, El Wak, Wote, Kimilili, Bungoma, Isiolo, Meru, Webuye, Iten, Homa Bay, Rumuruti, Maralal, Busia, Mandera, Kericho, Kitui, Lamu, Kajiado, Kapsabet, Marsabit, Lodwar, Kerugoya, Kwale, Hola, Mwatate.

    For more information or to place an order, contact us today.
