Single Stage Water-Ring Vacuum Pump in Bangladesh

Single Stage Water-Ring Vacuum Pump in Bangladesh

Single Stage Water-Ring Vacuum Pump in Bangladesh

Request For Quotation

working principle

A dynamically balanced cylindrical rotor with a hollow hub and a series of curved blades is rotated freely in the eccentric casing. The sufficient sealing water / liquid forms a solid ring on the periphery of the casing, due to the centrifugal force, the rotor is rotated in the eccentric casing, the rotating blade creates working spaces whose volume increases as the rotor rotates from lower to upper vertex and decreases as the rotor rotates from upper vertex to lower vertex. The uniform distribution of working spaces on rotor periphery results in continuous suction and exhaust of gases.

Technical Specifications

MODELMAX. CAPACITY (M3/Hr.)WATER REQD. ( LPM )
REC. MOTOR ( KW / HP )
MOTOR SPEED ( RPM )
MOTOR FRAME SIZE
IVS 49 49072.2 / 3285090 L
IVS 81 81093.7 / 52850100 L
IVS 12312313 5.5 / 7.52850132 S
IVS 165175 165.5 / 7.51450132 M
IVS 220220207.5 / 101450132 M
IVS 3303302811 / 151450160 M
IVS 4404403515 / 201450160 L
IVS 7257255522 / 30980200 L
IVS 8508507030 / 40980225 M
IVS 108010808530 / 40 ( 37 / 50 )980225 M / 250 M
IVS 15001700 12045 / 60 ( 55 / 75 )725280 M / 315 S
IVS 20802150 15075 / 100725315 M
IVS 2800280020090 / 120725315 L

material of construction

  • The Pump can be supplied in several materials to suit various applications;
  • Cast Iron
  • Partially or Complete Bronze, SS 304, SS316, Alloy 20, Hastelloy – C,
  • Rubber Lined
  • Other as per customer requirement

features

  • The Pump can be supplied in several materials to suit various applications;
  • Cast Iron
  • Partially or Complete Bronze, SS 304, SS316, Alloy 20, Hastelloy – C,
  • Rubber Lined
  • Other as per customer requirement
  • get in touch

    Application

    Company Overview:

    IVC Pumps Pvt. Ltd. is a Manufacturer, Supplier and Exporter of Single Stage Water-Ring Vacuum Pump in Bangladesh.

    Our Manufacturing Unit is in Ahmedabad, Gujarat, India.

    A single stage water-ring vacuum pump is a type of positive displacement pump that utilizes a water ring to create a vacuum.

    This design is particularly effective for handling various gases and vapors in industrial applications. The pump operates by drawing in air or gas and compressing it through a rotating impeller, creating a vacuum effect.

    Features:

    Efficient Vacuum Generation: The water ring creates a consistent vacuum level, making these pumps suitable for many applications requiring reliable vacuum conditions.

    Low Maintenance: The design minimizes wear and tear, resulting in lower maintenance costs compared to other types of vacuum pumps.

    Operation with Liquids: These pumps can handle condensable vapors and humid air without damage, making them ideal for applications involving liquids and gases.

    Continuous Operation: Designed for continuous use, they provide steady performance over extended periods.

    Environmentally Friendly: Water is often used as the sealing fluid, making it a sustainable choice compared to oil-sealed pumps.

    IVC Pumps Pvt. Ltd. is a Manufacturer, Supplier and Exporter of Single Stage Water-Ring Vacuum Pump in Bangladesh including Bhairab, Bogra, Brahmanbaria, Chandpur, Chowmuhani, Chudanga, Comilla Sadar Dakshin, Feni, Jessore, Jhenaidah, Kadam Rasul, Kaliakair, Kushitia, Naogaon, Narsingdi, Pabna, Saidpur, Satkhira, Savar, Tangail, Tarabo, Tongi, Chittagong, Dhaka, Khulna, Rajshahi, Barisal, Mymensingh, Sylhet, Rangpur, Dinajpur.

    For further details and inquiries, please feel free to reach out to us.

    View Product: Click Here

    Get in touch with us to
    find out more about our offerings.
