working principle

The Vacuum Pump of the IVOL Series are Single Stage, Oil Lubricated Rotary Vane Vacuum Pump with Oil Re-Circulation System. The Lubricant is rated for continuous operation at high intake pressure so that pump may be used in a versatile manner in most rough Vacuum Application. They are used for Suction of air also in presence of water vapour and for continuous industrial use.

Technical Specifications

MODELMAX. VACUUM MBAR(TORR)MAX. CAPACITYOIL CAPACITY ( LTRS )
REQ. MOTOR ( KW / HP )
MOTOR SPEED
IVOL - 200.5 (0.3)2010.5 / 0.751450
IVOL - 400.5 (0.3)4020.75 / 11450
IVOL - 650.5 (0.3)652.51.5 / 21450
IVOL - 1000.5 (0.3)10032.2 / 31450
IVOL - 1500.5 (0.3)15043.7 / 51450
IVOL - 3000.5 (0.3)30085.5 / 71450

material of construction

  • Housing: The pump housing, typically made of cast iron or aluminum alloy, forms the main body of the pump. It contains the internal components and provides structural support.
  • Rotor: The rotor is a central component of the pump and is mounted on a shaft connected to a motor. It typically consists of multiple vanes (usually made of carbon or composite materials) that are evenly spaced around the circumference of the rotor.
  • Vane Sliding Mechanism: Each vane is mounted on a slotted rotor, allowing it to slide in and out as the rotor rotates. This sliding mechanism creates the pumping action by trapping and compressing gas between the vanes and the housing.
  • features

  • High pumping speed over the range of absolute pressure 1000 mbar – 0.5 mbar
  • High water vapour tolerance and low noise level
  • No pollution
  • Air Cooled
  • Built in Anti Suck-Back System
  • Easy Maintenance.
  • get in touch

    Application

    Company Overview:


    IVC Pumps Pvt. Ltd. is a Manufacturer, Supplier and Exporter of Oil-Lubricated Rotary Vane Vacuum Pump in South Africa.

    Our Manufacturing Unit is in Ahmedabad, Gujarat, India.

    An oil-lubricated rotary vane vacuum pump creates vacuum or negative pressure as a sophisticated piece of equipment.

    It operates by utilizing rotating vanes within a cylindrical housing.

    These pumps are widely used in various industrial applications, including:
    Vacuum packaging
    Material handling
    Pharmaceuticals
    Chemical processing

    Operational Mechanism:


    At its core, the pump consists of a rotor with multiple vanes that are mounted eccentrically within a cylindrical chamber.
    As the rotor spins, centrifugal force pushes the vanes outward, creating a seal against the inner surface of the housing.
    This action traps a volume of gas between the vanes, which decreases in volume as the rotor continues to rotate.
    This reduction in volume results in the compression and expulsion of the gas through an exhaust port.

    Features:


    High pumping speed (1000 mbar – 0.5 mbar)
    High water vapor tolerance
    Low noise level
    No pollution
    Air-cooled
    Built-in anti suck-back system
    Easy maintenance

    IVC Pumps Pvt. Ltd. is a Manufacturer, Supplier and Exporter of Oil-Lubricated Rotary Vane Vacuum Pump in South Africa including locations Johannesburg, Cape Town, Durban, Pretoria, Gqeberha, Bloemfontein, East London, Pietermaritzburg, Kimberley, Mbombela, Polokwane, George, Rustenburg, Mthatha, and Stellenbosch.

    For detailed information or inquiries, please feel free to contact us.
