working principle

Manufacturing mechanical vacuum booster systems involves meticulous steps to ensure quality and efficiency. The process commences with design and engineering, crafting detailed blueprints based on performance requirements and standards. Materials are then procured, encompassing metal parts, seals, valves, motors, and electronics. Next, components are fabricated through machining, casting, or forging. Skilled technicians meticulously assemble these parts, adhering to precise procedures and rigorous quality control measures. Testing follows suit, scrutinizing functionality, safety, and performance under diverse conditions. Quality control remains paramount throughout, with inspections conducted at each stage. Post-testing, systems are securely packaged for shipping, often accompanied by installation support and ongoing customer service. Continuous improvement is pursued through feedback analysis, fostering innovation and product enhancement.

Technical Specifications

AIR COOLED SERIES MODEL && ITS DETAIL TECHNICAL SPECIFICATION

PARTICULARSIVMA-9IVMA-11IVMA-13IVMA-15IVMA-17IVMA-19IVMA-21IVMA-23IVMA-25IVMA-27IVMA-29IVMA-31
DISPLACEMENT LPM @1450 RPM22503650500075001650019500310005000087500137500232000321500
DISPLACEMENT LPM @2850 RPM450073001000015000233003900062000***************
Recommended Motor KW @1450 RPM1.11.12.22.23.75.55.512.518.5304590
Recommended Motor KW @1450 RPM2.22.23.73.75.57.511***************
Max P(m bar)1001001001009085656060555050

WATER COOLED SERIES MODEL & ITS DETAIL TECHNICAL SPECIFICATION

PARTICULARSIVMW-10IVMW-12IVMW-16IVMW-22
DISPLACEMENT LPM @1450 RPM4500140003600057000
DISPLACEMENT LPM @1450 RPM9100280007200011400
Recommended Motor KW @1450 RPM2.23.75.57.5
Recommended Motor KW @1450 RPM3.75.51115
Max P(m bar)75655050

material of construction

  • Construction of Vacuum Booster Compressor involves Two Counter Rotating Rotor ( Lobe )  with a Special Contour. These Rotate with a Very Finite and Sharp Clearance and without any Physical Contact. Variance in design offers Twin Lobe Booster in air cooled or water-cooled execution.
  • The Booster are Relatively Consume Less Power and Deliver High Performance. They provide and Improvement in Vacuum of the Order of 0.001 Torr. They Generate Higher Pumping Speeds and That too at Low Pressure.
  • The Boosters are used in series with any Vacuum Pumps Like Watering, Oil Seal and Dry Type Or Ejector.
  • The Booster are help to achieve a reduce Downtime for Vacuum Machine.
  • They are Properly installed and Maintain Well, they provide years of Uninterrupted Service.
  • features

  • Vacuum Boosters are Power Efficient. Very often a Combination of Vacuum Booster and Suitable Back up Pump Result in Reduced a Power Consumption Per Unit of Pumping Speed. They Provide High Pumping Speed Even at Low Pressure.
  • Mechanical Vacuum Booster is Dry Pump, as it Does Not Use any Pumping Fluid.
  • Low Power Consumption Compare to any Type of High Vacuum Pump.
  • High Volumetric Efficiency.
  • Enables Operations in High Vacuum and Large Pumping Speed at Very Low Power Consumption and Hence Very Short Payback Period.
  • Low Maintanance.
  • Application

    IVC Pumps Pvt. Ltd. is a leading Mechanical Vacuum Booster System Manufacturer and Supplier in Indonesia.

    A Mechanical Vacuum Booster System enhances the performance of standard vacuum pumps by significantly increasing pumping speed and achieving deeper vacuum levels.

    IVC Pumps Pvt. Ltd., based in Ahmedabad, designs and manufactures these booster systems to integrate seamlessly with primary pumps—such as water-ring, oil-sealed, or dry vacuum pumps—providing fast, efficient, and reliable evacuation performance.

    A mechanical vacuum booster, often known as a Roots-style booster, consists of two intermeshing rotors in a precision-matched housing.

    As they rotate, they compress and transfer gases from the vacuum chamber to the primary pump, creating a more powerful vacuum.

    This system works in tandem with a primary pump, enhancing system capability while avoiding wear on either unit.

    Why Choose IVC Pumps’ Mechanical Vacuum Booster System?

    Industry Expertise: A trusted Indian manufacturer since 2010, offering custom-engineered solutions.
    Robust Specs: Capacities from 2,250 to 321,500 LPM; power ratings from 1.5 HP to 120 HP; ultimate vacuum up to 0.001 Torr.
    Flexible Cooling: Air-cooled and water-cooled designs available.
    Energy-efficient & Eco-friendly: Dry pump design with low power consumption and minimal emissions.
    Easy Integration: Compact, modular units that can be retrofitted into existing systems.
    Maintenance Advantages: Contact-free rotors mean less wear and lower servicing requirements.

    Applications:

    Chemical Industry
    Pharmaceutical Industry
    Plastic Industries
    Mining
    Oil & Gas
    Food Dairy

    Frequently Asked Questions (FAQs):

    Q1: What vacuum levels can IVC boosters achieve?
    With suitable primary pumps, they can reach 0.001 Torr, offering deeper vacuum than pumps alone.

    Q2: Are there cooling options available?
    Yes—choose from air-cooled or water-cooled models depending on your needs.

    Q3: Can it be added to existing pumps?
    Absolutely—it’s engineered for seamless integration with current vacuum setups.

    Q4: How are energy savings achieved?
    By offloading work from primary pumps and using dry mechanics, power usage significantly drops.

    Q5: What maintenance do boosters require?
    Minimal: no pumping fluid in chamber, contact-free rotors, occasional inspection and lubrication of timing gears.

    IVC Pumps Pvt. Ltd. is a Mechanical Vacuum Booster System in Indonesia Including other locations Jakarta, Surabaya, Bekasi, Bandung, Medan, Depok, Tangerang, Palembang, Semarang, Makassar, South Tangerang, Batam, Bogor, Pekanbaru, Bandar Lampung, Padang, Samarinda, Malang, Tasikmalaya, Balikpapan, Serang, Banjarmasin, Pontianak, Denpasar, Jambi, Cimahi, Surakarta, Kupang, Manado, Cilegon, Mataram, Jayapura, Bengkulu, Palu, Yogyakarta, Sukabumi, Ambon, Kendari, Cirebon, Dumai, Pekalongan, Palangka Raya, Binjai, Kediri, Sorong, Pematangsiantar, Banjarbaru, Tegal, Banda Aceh, Tarakan, Probolinggo, Singkawang, Lubuklinggau, Padang Sidempuan, Tanjungpinang, Bitung, Pangkalpinang, Batu, Pasuruan, Banjar, Gorontalo, Ternate, Madiun, Salatiga, Prabumulih, Lhokseumawe, Langsa, Bontang, Tanjungbalai, Tebing Tinggi, Metro, Palopo, Bima, Baubau, Parepare, Blitar, Pagar Alam, Payakumbuh, Gunungsitoli, Mojokerto, Bukittinggi, Kotamobagu, Magelang, Tidore Islands, Tomohon, Sungai Penuh, Subulussalam, Pariaman, Sibolga, Tual, Solok, Sawahlunto, Padang Panjang, Sabang.

    For detailed information or inquiries, please feel free to contact us.
